Measuring Range

0 to 100 % Oxygen

Signal Output¹

9 -14 mV

Response Time T90

6 seconds

Accuracy ²

+/- 1% of signal

Drift ²

< 2%

Linearity

+/- 1%

Repeatability

+/- 0.5%

Temperature Coefficient

NONE - signal output is temperature compensated

Operating Temperature

0 to 40°C

Recommended Storage Temperature

5 to 35°C - Intermittent exposure up to 50oC acceptable

Recommended Flow Rate

0.5 - 5 SCFH

Humidity Non-Condensing2

0 - 98% RH

Expected Life³

36 months

Recommended Storage

6 months

Warranty4

12 months

Electrical Connections

Front

3-PIN Molex

M16 x 1 thread
