Measuring Range

0 to 100 Percent Oxygen

Signal Output¹

10-15.5 mV

Response Time T90

12 seconds

Accuracy ²

+/- 1% of signal

Drift ²

< 2%

Linearity

+/- 1%

Repeatability

+/- 0.5%

Temperature Coefficient

NONE - signal output is temperature compensated

Operating Temperature

0 to 40°C

Recommended Storage Temperature

5 to 35°C - Intermittent exposure upto 50o  C acceptable

Recommended Flow Rate

0.5 - 5 SCFH

Humidity Non-Condensing2

0 - 98% RH

Expected Life³

60 months

Recommended Storage

6 months

Warranty4

12 months

Electrical Connections

Front

Two 22 guage wires

Hex Slip-on
