• Intrinsically safe circuit design, safe and reliable
• Triple alarm prompt of sound, light and vibration
• Beautiful appearance, convenient operation, accurate measurement, strong and durable
• 2.4-inch ultra-high definition liquid crystal color screen, perfectly presentingvarious gas detection indicators
• 16 bit data acquisition chip + 32-bit nano microprocessor, with higher resolution and faster reaction speed
• High strength aluminum alloy shell, resistant to acid, alkali, cold, heat, impact and flame
• Imported gas sensor with original packaging, high precision, strong stability, low error rate and good linearity
• The customer can set the high and low alarm value, alarm prompt switch andother functions as required
• 2900ma large capacity lithium battery, electrochemical sensor can work continuously for more than 20 hours
• One key switch between ppm and Mg / m3 measuring range unit, simple and clear
• Micro USB design, compatible with most Android mobile phone chargers and chargers in the market
• Chinese and English display interface, Chinese and English real person voice prompt. Applicable to all people
• Support curve drawing, convenient to observe the periodic state of gas concentration
Alarm mode | Sound, light, vibration |
working | -20℃~+50℃(Special requirements to be customized) |
Working | ≤95%RHnon-condensing |
Working | -30kPa~200kPa |
Appearance | 130x63×36mm(LxWxH) |
weight | About500g |
Detection | Pump suction type |
Protection | IP66 |
Pump flow | 300-500CC/Min |
Texture of | Aluminum alloy; strong, wear-resistant and corrosion-resistant |
Executive | GB15322.1-2003,GB3836.1-2010,GB3836.2-2010,GB3836.4-2010 |
data storage | 4000 alarm records |
Charging | DC 5V |
voltage | 3.7VDC(Built in 2900ma rechargeable polymer power supply) |
USB charger(DC 5V),Data line ,Instructions ,Certificate
